Available in 30Ah (408Wh), 40Ah(544Wh), or 60Ah(816Wh) Battery Configurations | Orange or Tan Rugged Case

The DeployNet™ is a rugged, self-contained internet solution designed for fast deployment anywhere reliable connectivity is needed. Built inside a durable hard case, it provides dependable internet service wherever your Starlink Mini has a clear view of the sky—simply press the illuminated power switch and you're online.

No loose wires. No complicated setup. No external batteries to manage.
Everything is securely mounted, protected, and ready to deploy.

DeployNet™ can be operated while connected to its charger, allowing continuous operation during extended deployments.

Note: A Starlink Mini antenna and active service subscription are required for operation and are not included with this system.

Whether you're supporting emergency operations, working in remote locations, traveling off-grid, or preparing for outages, DeployNet™ delivers reliable connectivity in a compact, field-ready system.

---

Choose Your Configuration

Battery Capacity Options

DeployNet™ 30 — Standard Runtime

Ideal for typical deployments, travel, and backup internet.

Battery Capacity: 30Ah - 408Wh
Typical Runtime: 8–12 hours
Approximate Weight: 18 lbs

---

DeployNet™ 40 — Extended Runtime

Provides longer operation between charges while maintaining a compact footprint.

Battery Capacity: 40Ah - 544Wh
Typical Runtime: 11–16 hours
Approximate Weight: 19 lbs

---

DeployNet™ 60 — Maximum Runtime

Designed for extended missions, remote work sites, and multi-day operations where maximum runtime is critical.

Battery Capacity: 60Ah - 816Wh
Typical Runtime: 16–24 hours
Approximate Weight: 23 lbs

This configuration provides approximately:

• 100% more runtime than the 30Ah system
• 50% more runtime than the 40Ah system

---

DeployNet™ 80 — Extended+ Runtime

Designed for extended missions, remote work sites, and multi-day operations where maximum runtime is critical.

Battery Capacity: 80Ah (1088Wh)
Typical Runtime: 24-32 hours
Approximate Weight: 27 lbs

This configuration provides approximately:

• 33% more runtime than the 60Ah system
• 100% more runtime than the 40Ah system
• Nearly 3× the runtime of the 30Ah system

How We Calculate Runtime

Battery runtime is often overstated in marketing. We prefer to give you real-world expectations you can rely on in the field.

Our runtime estimates are based on:

• Actual device power draw (not idle or best-case numbers
• Battery management system (BMS) cutoff — batteries do not drain to 0
• System losses from voltage conversion and wiring

---

Case Color Options

• Rescue Orange — High visibility and easy identification in the field
• Tan — Low-profile appearance suitable for general or tactical environments

---

Key Features

• One-switch operation — Press and connect in seconds
• Illuminated waterproof metal power switch
• Can be used while charging
• Self-contained portable internet system
• Integrated LiFePO4 battery power
• Built-in USB and 12V charging ports
• Digital voltmeter for battery monitoring
• Rugged protective hard case
• All stainless steel hardware throughout
• Clean, serviceable internal layout
• Designed for transport and field deployment

---

Power and Charging

DeployNet™ includes a 110V battery charger, allowing convenient recharging from:

• Standard household outlets
• Generators
• Vehicle inverters
• Portable power stations

The system is designed to operate normally while connected to the charger, making it suitable for:

• Command posts
• Remote job sites
• Emergency response
• Disaster recovery
• Extended deployments
• Backup internet during outages

---

Integrated Power Ports

The system includes a multi-function waterproof power panel that allows you to charge additional equipment directly from the DeployNet™ system.

Built-in Ports

• USB-C fast charging port
• Dual USB-A charging ports
• 12V accessory (cigarette-style) socket
• Integrated power switch
• Digital voltmeter
• Waterproof aluminum housing

This allows DeployNet™ to function as both an internet system and a portable power source.

---

Case Specifications

The DeployNet™ system is built inside a rugged:

Apache 3800 Protective Case

External Dimensions:
16.9 in L × 14.7 in W × 6.7 in H

Internal Dimensions:
15.2 in L × 12.2 in W × 5.7 in H

Construction Features:

• Impact-resistant polymer case
• Weather-resistant gasket seal
• Dual latches
• Pressure equalization valve
• Molded carry handle
• Stainless steel mounting hardware

---

Battery Specifications

Battery Type:
LiFePO4 (Lithium Iron Phosphate)

System Voltage:
12V

Capacity Options:

30Ah - 408Wh
40Ah - 544Wh
60Ah - 816Wh

Cycle Life:

Typically:

2,000–4,000 charge cycles

Expected Service Life:

Up to 10 years under normal use

---

Runtime Comparison

DeployNet™ 30:
8–12 hours

DeployNet™ 40:
11–16 hours

DeployNet™ 60:
16–24 hours

Actual runtime depends on:

• Network usage
• Ambient temperature
• Device load
• Charging conditions

---

Weight

Approximate System Weight (with antenna and charger):

DeployNet™ 30 — 18 lbs
DeployNet™ 40 — 19 lbs
DeployNet™ 60 — 23 lbs

Weight includes:

• DeployNet™ system
• Internal battery
• Starlink Mini antenna
• 110V battery charger
• Installed hardware and wiring

---

Typical Use Cases

Emergency response
Search and rescue
Remote job sites
Construction and utilities
Farming and ranching
Camping and RV travel
Mobile command posts
Disaster recovery
Backup internet during outages
Off-grid operations

---

What’s Included

DeployNet™ portable internet system
Internal LiFePO4 battery (30Ah, 40Ah, or 60Ah depending on selection)
110V battery charger
Integrated USB and 12V power ports
Illuminated power switch
Fully assembled and ready to use

---

Important Requirement

A Starlink Mini antenna and service subscription are required for operation and are not included with this system.

This unit is designed to power and protect your existing Starlink Mini hardware.
